How To Make a Finishing Mallet

https://youtu.be/-yo9z73_pu0

I recently made a joiner's mallet, but it has a hard face and can ding up work easily. I needed a mallet for finishing with a leather face and softer head. Much of this build is just like the last one with more carving and leather. Also, rather than building it out of firewood, I am using a scrap of cherry that was perfect for this build. One can never have enough mallets.

Tools Needed

#4 Hand plane setup for smoothing: http://amzn.to/2hc6LQZ

Square: http://amzn.to/2ia9M3Z

Marking Gauge: http://amzn.to/2i0jvHx

Panel Saw: http://amzn.to/2hjAura

Bevel up Low Angle Plane: http://amzn.to/2ikc9Sd

Round Bottom Spokeshave: http://amzn.to/2hZRxvf

Marking Knife: http://amzn.to/2hPHf34

Brace: http://amzn.to/2hPEs9Y

Bit Set: http://amzn.to/2hZVT5T

Chisel Set: http://amzn.to/2i26mzX

Block Plane: http://amzn.to/2ikkaqg

Carving V-Tool: http://amzn.to/2kf8OjO

Card Scraper: http://amzn.to/2lGyFF0

Supplies used

Firewood: free on craigslist, look for dried or something that has been sitting out for a year or more.

Scrap Leather: http://amzn.to/2lGx8x8

Boiled Linseed Oil: http://amzn.to/2hPEUVO

Paste Wax: http://amzn.to/2inlN23

DAP Contact Adhesive: http://amzn.to/2laGKyw

Glue Stick: http://amzn.to/2lGFnuF

Related Videos

Joiner's Mallet from Firewood: https://www.youtube.com/watch?v=CO4QtjMuN4Q

Frame Saw Build: https://www.youtube.com/watch?v=Z1fEYcxM9Ic

BLO and Paste Wax: https://www.youtube.com/watch?v=KvSvmOwmNV8

Paul Seller’s Mallet build: https://www.youtube.com/watch?v=u31Ixu6mSHY

Cut a Block for a Head


For a finishing mallet, you will want a softer head like Cherry or Douglas fir. Most of the time, for me, the best place to get stock is out of a piece of dried firewood. But in this case, I had a slab on hand that was the perfect size. It should be about 2.5-3" thick about 6" long and 4" tall. Cut one side and square it up, then, square the other sides off of that first reference piece.

Cut the Handle


The handle should be about 14-18" long about 3/4-7/8" thick and 1 1/2" wide. Mine is made out of a scrap of white oak I had in the shop, but you can make it out of whatever you want. Then, start by drawing a line from one corner to a point 3/8" in on the other end. This will turn the handle into a long wedge that will self-hold itself in the head of the mallet. You can then use a plane to bring it down to that line.

Cut Mortise for Handle


Start by placing the head on the handle with about 1 1/2" of the handle sticking up above the top. Next, use a marking knife to mark either side of the handle on the head. This will give you placement marks that tell you how wide the wedge of the handle will be at that point. With a square, draw those lines across the top and bottom of the mallet, then, place the handle on top o the mallet and draw its thickness. This will give you a rectangle on the top and bottom of the head that you can now cut out. Use a brace and bit to remove most of the waste then come in with a chisel and slowly cut back to those marks. Next, test the fit with the handle. You will see where more needs to come out. Keep repeating this till you have a nice fit between the head and handle.

Shape the Head


I like to put a bit of an angle on both faces of the mallet so that it strikes flat on the work. I draw a line that starts in 3/8" at the bottom and goes up to the top corner. Then, follow the line with a saw and cut it out.  Save these wedges, you will need them in the next step. After that, I can smooth it out with a low angle plane and put a chamfer on all the corners. You may also want to shape the handle to feel good. For that, I use a spoke shave.

Glue on Leather


I have some scraps of leather left over from other projects that will work perfectly. Whatever you have will work great. I apply the contact adhesive to both the head and the leather and let it set until it gets tacky. I use the wedges from the last step to clamp it in the vice and let it sit overnight. But while it is in the vise, I think it is time to do a bit of carving.

Carve the Sides


While it is in the vise, I apply carving patterns with a glue stick. I like the Celtic weave and this was the perfect opportunity to put my logo on. For the carving, I use a V-tool and just follow the line on the paper. With light quick taps on the chisel, it is really easy. Most people can pick this up in 20-30 minutes of work. For the weave, I run it along both sides of the thick black line. Then when done I use a card scraper to remove the pattern and smooth that side of the mallet for finish.

FINISH IT!!!


I use a knife to remove the excess leather at about a 45-degree angle. then give the whole mallet a boiled linseed and paste wax finish. I just love the way it feels in the hand! And there you go, now you have a finishing mallet ready to lightly pound on things.
